1、UG CAM术语中英文对照表AActivation Range自动进刀范围Add Arcs加圆弧Additional Passes附加轨迹Allow Oversize TOOL允许偏大刀具Append追加Approach趋进刀轨Approach Maker趋进标记Arc Center Probe探头弧心Area Milling区域铣削At Angle To DS与驱动面成角度At Angle To PS与零件面成角度Auxfun辅助功能Avoid避让Avoidance Geometry避让几何体Away From Line远离参考线Away From point远离参考点BBandwidth带

2、宽Barrel Cutter鼓形刀Blank Boundary毛坯边界Blank Distance毛坯距离Blank Geometry毛坯几何体Blank Stock毛坯余量Blank毛坯Blind Hole盲孔Bottom Regions底面区域Boundaries边界Boundary Approximation近似（增加沿边界铣削刀轨）Boundary Face边界面Boundary边界Break Chip断削钻CCAM Customization 用户化CAM ObjectCAM对象 Case情形Cavity Mill型腔铣Cclw逆时针Check Boundary检查边界Check G

3、eometry检查几何体Circular Feedrate Compensation圆弧进给速度补偿Circular-Perp/Par To TA在垂直刀具/平行于的平面输出圆弧插补Clamp夹紧Cleanup Geometry清理几何体Clearance Plane安全平面Climb Cut顺铣Closed封闭Clst Actions刀具位置源文件作用Clst Maneger刀具位置源文件管理器CLSF(Cutter Location Source File)刀具位置源文件Ccw顺时针CNC计算机数字控制Collision Check碰撞检查Convave Corner凹拐角Configur

4、ation配置Constant常量Contact(Tool Position)接触（刀具位置）Continuous Path Motion连续刀轨运动Control Points进刀控制点Conventional Cut逆铣Convex Corner凸拐角Coolant Off冷却液关Coolant On冷却液开Corner And Feed Rate Control拐角及其进给速度控制Corner Angle拐角Curve Directrix曲线，准线Curve/Point Drive曲线和点驱动Customizing客户化Cut Angle切削角Cut Area切削区域Cut Depth切

5、削深度Cut Level切削层Cut Method切削方法Cut Order切削顺序Cut Region切削区域Cut Region Start Point切削区域起始点Cut Step切削步距Cut切削Cutter Compensation刀具补偿Cutter Diameter Compensation刀具直径补偿Cutter Length Compensation刀具长度补偿Cutting切削参数Cutting Move切削运动Cycle Definition Events固定循环定义事件Cycle Move Events固定循环运动Cycle Parameter固定循环参数Cycle P

6、arameter Set固定循环参数组Cycle 固定循环DDefinition File Elements定义文件要素Definition File定义文件Depth First深度优先Depth Offset深度偏置Directional Steep指向陡峭面Drilling Tool钻头Drive Curve Lathe驱动曲线车削Drive Method驱动方法Dual 4-Axis On Drive双四轴于驱动面上Dual 5-Axis On Part双四轴于零件上Dumb Objects关联对象Dwell暂停时间EEnd -Of-Path Commands刀轨结束命令Engage/

7、Retract进刀/退刀方法Engage Motion 进刀运动Engage 进刀Event事件Environment环境Event Generator事件生成器Event Handler事件处理器Exclude Face排除的面Ext.Tan相切延伸FFacing面铣Fan扇形Far Side远侧Feed Per Tooth每齿进给量Feed Rate进给速度Filter Methods过滤方法Final Retract最终退刀Finish Path精加工刀轨Finish Stock最终余量First Cut 切削的第一刀（进给量）Fixed Contour固定轴曲面轮廓铣Fixed Dep

8、th固定深度F1 Stck/Min Clr零件底面余量/最小安全距离Flip Material材料侧反向Floor底平面Floor&Island Tops底平面和各岛屿的顶面Floor Only只切削底平面Floor Cut清根切削Floor Boundary遵循边界方向Floor Check Geometry遵循检查几何体形状Floor Periphery遵循外轮廓形状Floor predrill Points沿着预钻孔点Floor Start Points沿着起始点From Maker从标记点GGenerate生成Geometry几何体Geometry Groups几何体组Geometry

9、 Objects几何体对象Geometry view几何体视图Goto转移到Gouge Check Area过切检查区域Gouge Check 过切检查Graphical Postprocessing Module(GPM)图形后处理模块Grooving Tool车槽刀Group组HHelical按螺旋线（斜坡进刀）Hookup Distance连接间隙距离IIgnore Chamfers忽略倒角Ignore Holes忽略孔Ignore Islands忽略岛屿Incremental Side Stock侧余量增量Inheritance继承Initial Engage初始进刀Insert插入I

10、nternal Engage内部进刀Internal Retract内部退刀Interpolate插补Inward向里Island岛屿LLathe Cross-Section横切面（用于车削）Lathe Finish精车Lathe Groove车槽Lathe Rough粗车Lathe Thread车螺纹Layer/Layout视图/布局Lead And Lag前导角和后导角Level First水平优先Levels At Island Tops切削各岛屿的顶面Libraries库Linear Only只输出直线插补List显示列表Loop循环MMachine Control机床控制Machin

11、e Control Events机床控制事件Machine Data File Generator(MDFG)机床数据文件生成Machine Tool机床Machine Tool Kinematics机床运动学Machine Tool Motion Control机床运动控制Machine Tool Type Options机床类型选项Machine Tool View刀具视图Machining Environment加工环境Machining Method View加工方法视图Manufacturing 制造（加工）Manufacturing Output Manager加工输出管理器Mat

12、erial Side材料侧Max Concavity最大凹度MCS(Machine Coordinate System)加工坐标系MDF(Machine Data File)机床数据文件Method Groups方法组Method Objects方法对象Mill Area铣削区域Mill Boundary铣削边界Mill Geometry铣削几何体Milling Tool铣刀Min Clearance最低安全平面Min Cut Length最小切削段长度Minimum Clearance最小安全距离Motion Output运动输出格式Move Events运动事件Move Status运动状

13、态Movement运动形式Multi-Depth多层切削NNC( Numerical Control)数控Near Side近侧No Cycle无固定循环Non-Cutting Move非切削运动Non-Steep避让陡峭面Non-Steep Face非陡峭面Normal To Drive与驱动法向一致Normal To DS与驱动面一致Normal To Part与零件法向一致Normal To PS与零件面法向一致Nurbs(Non-Uniform Rational B-SplineNurbs格式输出OOffset/Gouge刀具偏置过切检查Omit省略On Tool Position在刀

14、具中心位置上On Lines按直线（斜坡进刀）On Shape按外形（斜坡进刀）On Surface在曲面上ONT(Operation Navigation Tool)操作导航工具Open开口Operation Objects操作对象Operation 操作Operator Message操作者提示Optimize优化Optional Skip Off程序段跳段结束Optional Skip On程序段跳段开始Origin原点Output File Validation输出文件有效Output Plane输出插补平面Outward向外Overlap Distance拾接距离PParallel

15、To Ps平行于零件面Parallel To Ds平行于驱动面Parameter Groups参数组Parent父节点Part Boundary零件边界Part Containment零件包容Part Floor Stock零件底部余量Part Geometry零件几何体Part Side Stock零件侧面余量Part Stock零件余量Pattern Center同心圆模式中心Pattern 切削模式Peck Drill啄式钻Permanent Boundary永久边界Planar Mill平面铣Pocket内腔Point To Point Motion点到点运动Point To Poin

16、t点位加工Postprosessor后置处理Power功率Pre-Drill Engage Points预钻孔进刀点Pre-Drill 预钻孔Preference预设置Prefun准备功能Prepare Geometry预加工几何体Preprocess预处理Profile轮廓Program Groups程序组Program Objects程序对象Program Order View程序顺序视图Program 程序Proj DS Normal沿驱动面法向投射Proj PS Normal沿零件法向投射Projection Vector投射矢量RRadial Cut径向切削Ramp Angle斜坡角

17、度Ramp Down Angle向下斜坡角度Ramp Up Angle向上斜坡角度Ramp Type切削范围Range切削范围Range Depth切削范围深度Rapid快速进给速度Rapto Offset快进偏置 Rcs(Reference Coordinate System)参考坐标系Region Connection区域连接Region Sequencing切削区域的顺序Register Number（刀具补偿）寄存器号Reject拒绝Relative To Drive 相对于驱动面Relative To Part相对于零件面Relative To Vector相对于矢量方向面Repla

18、y重新显示Reset From Table从表中重新设置Retract Clearance退刀安全高度Retract Motion退刀运动Retract 退刀Return刀具返回Reverse Boundary反向边界方向Rotate旋转Rtrcto退刀距离SSafe Clearance安全距离Same As Drive Path与驱动轨迹刀具轴相同Scallop残留高度Seed Face种子面Select Head选择主轴头Sequence Number顺序号Sequential Milling顺序铣Set Modes设置模式Setup Events事件设置Setup 设置Shop Docu

19、mentation车间工艺文档Slowdowns降速Smart Objects相关联对象Spindle Off主轴停止Spindle On主轴启动Spindle Speed主轴转速Spiral螺旋驱动Standard Bore标准镗Standard Bore ,Back标准镗，慢速退刀Standard Bore ,Drag标准镗，偏移主轴退刀Standard Bore,Manual标准镗，手工退刀Standard Bore,No Drag标准镗，直接退刀Standard Drill标准钻孔Standard Drill,Break Chip标准钻削，断屑Standard Drill,Csink标

20、准钻削，沉孔Standard Drill,Deep标准钻削，深孔Standard Drive标准驱动铣Standard Tap标准攻螺纹Standard Text标准文本Start Marker起始点标记Startup Commands启动命令Steep Angle陡峭壁角度Steep Area陡峭壁区域Steep Faces陡峭面Steep陡峭壁Step步距（进给速度）Step Over步距类型/方向stepover行距Stock 余量Stopping Position刀具停止位置Sub-Operations子操作Surface Area曲面区域（驱动）Surface Region曲面区域（

21、特征）Surface Speed曲面表面切削速度Swarf Drive直纹面驱动TTangent To Ds相切于驱动面Tangent To Ps相切于零件面Tangential Edge Angle相切边角Tanto(Tool Position)相切（刀具位置）T-CutterT形刀Templates模板Temporary Boundary临时边界Temporary Plane临时平面The Event Generator事件生成器Thread Milling螺纹铣Threading Tool螺纹车刀Three Point Plane二点（圆心）探测Thru Fixed Pt通过固定点Thr

22、u Hole通孔Tilt倾角Tolerances-Intol/Outtol内公差/外公差Tolerant Machining容错加工Tool Axis刀具轴Tool Change换刀Tool Checker刀具检测器Tool Diameter刀具直径Tool Groups刀具组Tool Holder刀柄Tool Objects刀具对象Toolpath Actions刀轨动作Toolpath 刀位轨迹（刀轨）Tool Position刀具位置Tool Preselect刀具预选Tool刀具Toward Lines指向线Toward Point指向点Transfer Method转移方法Trave
