1、智能化系统一机房工程系统预算表单位：人民币元序号产品名称规格品牌单位数量单价金额一、数据中心机房1）、结构工程1钢质防静电地板m299.6240.0023,904.002钢质防静电通风地板块6288.001,728.002地板边支架m7124.001,704.003机柜出线口个1448.00672.004不锈钢踢脚板m7124.001,704.005踢脚板基层m7128.802,044.806顶地梁面防尘漆m220512.002,460.007乳胶漆L5842.002,436.008机房顶地面橡塑保温棉m211224.002,688.009镀锌铁皮m211230.003,360.0010方形铝
2、合金微孔吊顶板（标配三角龙骨）m299.672.007,171.2011金属彩钢标准壁板m288360.0031,680.0012彩钢板75龙骨m28896.008,448.0013墙板配件m28818.001,584.0014双面金属壁板门m26.6600.003,960.0015防火玻璃门Hl26.6720.004,752.0016大规格固定玻璃墙、隔断m252240.0012,480.0017操作工位个3360.001,080.0018地弹簧个3300.00900.0019上下门夹个660.00360.0020不锈钢拉手副3288.00864.0021机柜机架套16240.003,840
3、0022UPS机组机架套4420.001,680.0023台阶制作套1540.00540.0024固定斜坡m21360.00360.0025门口不锈钢包边套2774.001,548.00小计A123,948.002）、配电安装26封闭桥架（强电）m6120.00720.0027网格梯架（强电）m9228.002,052.0028封闭桥架（弱电）m4120.00480.0029网格梯架（弱电）m11228.002,508.0030电线管明配100m3360.001,080.0031WDZ-BYJ线敷设100m11192.002,112.0032WDZ-YJV100m31,020.003,060
4、0033WDZ-YJV100m11,740.001,740.0034WDZ-YJV100m0.51,800.00900.0035WDZ-YJV100m0.22,400.00480.0036WDZ-YJV100m0.49,600.003,840.0037WDZ-YJV100m0.312,600.003,780.0038市电柜进线电缆WDZ-YJV100m00.000.0039铜端子批11,800.001,800.0040插座套1212.00144.0041工业连接器套2436.00864.0042PDU电源套24180.004,320.0043接线盒安装只1001.98198.0044翘板开关
5、套531.50157.5045金属软管及接头m1003.78378.00小计B30,613.503）、独立接地46环状等电位铜排铜排m55108.005,940.0047绝缘子支架个1102.40264.0048静电泄漏地网m358.40294.0049双色连接线处503.60180.0050接地引上线m1236.00432.00小计C7,110.004）、结构照明51LED面板灯套21192.004,032.0052诱导疏散灯套260.00120.00小计D4,152.005）、防雷53三级防雷器片42,538.0010,152.0054三相断路器套4126.00504.00小计E10,65
6、6.006）、环境监控与节能控制主机配置55环境监控主控软件套16,000.006,000.0056Web端软件模块项11,200.001,200.0057管理主机台16,600.006,600.0058监控屏接口模块个11,167.601,167.6059本地协议转换软件模块套11,200.001,200.00二通讯报警60短信报警模块个1720.00720.0061短信报警系统个11,200.001,200.0062通讯卡（含半年费）张1288.00288.00三温湿度63温度传感器只12300.003,600.0064温/湿度一体传感器套6420.002,520.0065温湿度协议转换软
7、件模块套11,200.001,200.00四漏水检测系统66定位漏水检测模块个12,016.002,016.0067定位漏水感应绳（10米）根11,200.001,200.0068信号引出线（4米）个1216.00216.0069终止端根1144.00144.0070固定胶贴套290.00180.007124VDC工业电源个160.0060.0072漏水协议转换软件模块套11,200.001,200.00五精密空调监测与能量管理73信号转换模块个2756.001,512.0074精密空调监控管理软件套13,600.003,600.0075机柜抽风控制模块套12960.0011,520.0076
8、机柜抽风配件块1230.00360.0077机柜排风控制模块套12960.0011,520.0078机柜排风配件块1230.00360.00六不间断电源UPS监测79信号转换模块个2756.001,512.0080UPS协议转换软件模块套11,200.001,200.00七电源监测81配电协议转换软件模块套11,200.001,200.0082电量仪（含3个电流互感器）套71.440.0010,080.00小计F73,575.607）、机房配电柜83市电配电柜套126,400.0026,400.0084UPS配电柜套219,200.0038,400.0085UPS列头柜套221,600.004
9、3,200.0086空调动力柜套110,200.0010,200.00计G118,200.008）、机房空调新排风8725KW精密空调套2102,000.00204,000.0088上下水改造套2360.00720.00891.5p空调套17,200.007,200.0090排风机套13,840.003,840.0091新风机套13,360.003,360.0092风管米10222.002,220.0093风管米13174.002,262.0094保温型电动密闭风阀个11,020.001,020.0095电子除尘空气净化器个16,000.006,000.0096消声器个1780.00780.0
10、097多叶对开调节阀个2840.001,680.0098双层百叶送风口个2216.00432.0099电动防火阀个4816.003,264.0098单层百叶排风口个4180.00720.0099消声防雨百叶个1312.00312.00小计H237,810.009）、机房UPS电源系统100UPS主机套290,000.00180,000.00101蓄电池节96900.0086,400.00102电池架套32,160.006,480.00小计I272,880.0010）、机房机柜103服务器机柜台104,560.0045,600.00104配线机柜台23,600.007,200.00小计J52,8
11、00.0011）、机房机柜综合布线1056类24口快速配线架个22960.0021,120.00106理线器个2266.001,452.0010724口机架式光纤配线架个2960.001,920.0010824口双工LC适配器面板个2144.00288.00109LC耦合器个4860.002,880.00110多模尾纤条4866.003,168.00Ill多模光纤跳线条48204.009,792.0011224芯0M3室内多模光缆米1031.20312.001136类非屏蔽低烟无卤阻燃双绞线箱81,020.008,160.00小计K49,092.0012）、机房KVM114服务器切换管理系统A
12、KS4032（无线）台121,600.0021,600.00115DCIM-PS2模块台32336.0010,752.00小计L32,352.0013）、消防116七氟丙烷无管网灭火装置套19,600.009,600.00117七氟丙烷无管网灭火装置套26,000.0012,000.00118七氟丙烷药剂kg200168.0033,600.00119防护区标识牌块1108.00108.00120泄压口个1288.00288.00121泄压口防护区百叶罩个1360.00360.00122气体灭火控制器台112,000.0012,000.00123烟感探测器只5180.00900.00124温感探
13、测器只5168.00840.00125紧急启/停按钮只1336.00336.00126气体喷洒指示灯只1612.00612.00127声光警报器只4252.001,008.00128电源箱台13,540.003,540.00小计L75,192.00合计A1,088,381.10二、保安消控中心1）、地面工程1钢质防静电地板m2101240.0024,240.002地板边支架m7024.001,680.003不锈钢踢脚板m7055.203,864.004踢脚板基层m7028.802,016.005操作工位个4360.001,440.006乳胶漆L6042.002,520.007方形铝合金微孔吊顶
14、板（标配三角龙骨）m210172.007,272.008顶地梁面防尘漆m220812.002,496.009电视钢架槽钢8#吨0.33,600.001,080.0010电视钢架不锈钢板吨1.714,400.0024,480.00小计A71,088.002）、配电安装11电线管明配100m2360.00720.0012BYJ线敷设100m7192.001,344.0013BYJ线敷设100m1336.00336.0014WDZ-YJV100m11,020.001,020.0015WDZ-YJV100m0.15,400.00540.0016保安消控中心市电配电柜输入电缆WDZ-YJV100m07,
15、200.000.0017市电配电柜套19,600.009,600.0018UPS配电柜个16,600.006,600.0019机柜机架（50角钢焊接、含配电柜、UPS及蓄电池）套2342.00684.0020插座套912.00108.0021金属软管及接头m803.78302.4022接线盒安装只501.9899.00小计B21,353.403）、防雷、接地系统23三级防雷器片2294.00588.0024三相断路器套2139.50279.0025环状等电位铜排铜排m69114.007,866.0026绝缘子支架个1382.40331.2027接地跨接线处1004.68468.00小计C9,5
16、32.204）、UPS电原系统28消控室UPS主机套124,000.0024,000.0029蓄电池-Hj*32900.0028,800.0030电池架套12,160.002,160.0030IDF3后备式UPS套19,600.009,600.00小计D52,800.005）、接入机房31WDZ-BYJ100m21,020.002,040.0032WDZ-BYJ100m2192.00384.0033电线管明配100m2360.00720.00345P空开箱5P施耐只2180.00360.003512P空开箱12P施耐德只1420.00420.0036工业连接器16A恰套636.00216.0037PDU电源长和套6180.001,080.00小计E5,220.00合计B159,993.60说明：设备及材料费用合计：1,248,374.70工程安装费：249,674.94税金：89,882.98总计金额：1,587,932.62
